Page 30
Piping diagram
Fig 2
Operation manual
SEA Series Steam Sterilizers
26
Condense pipe
Exhaust solenoid valve
Normally open valve
Safety valve
Chamber
Drain
connection
Water tank
Used water tank
Manual water
filling exit
Let in air pump
Inner temperature sensor
Reserved connector (
G1/4)
Steam solenoid valve
(Normally closed valve)
Steam generator
waste water
drain connection
