5.2 Start a cycle
When water indication light is off, the machine can be started.
5.2.1Press
SELECT
to set one of the cycles. The key
toggles between the cycles at 121
,134
and cotton mode.
One of the indication lights turns on to show the cycle you
selected.(Fig 5-2)
5.2.2 You may select
DRY
key whether starts the fast sterilization cycle. Press
DRY
key, it will reduce the sterilization time. If you press the button"DRY" on the panel, there are
three selections, 1min(with 1min LED on), 5min(with 5min LED on) , and 10min(with two
LEDs off).
5.2.3 After select above settings, put the instruments into the autoclave which need sterilize.
Fig 5-3
Caution: Instruments that are ready to sterilize should
be placed in the tray not touching one another allowing
space for steam to pass through. It is suggested that the
tray holder be used to put the tray with instruments
inside the chamber to avoid scald. (Fig 5-3)
Fig 5-2
