Operation manual
SEA Series Steam Sterilizers
11
Fig1
The first way:
fig1,fig2
The second way:clockwise rotate the instrument rack by 90
based
on the first way
fig3,fig4
Notes: the circle stamped angle is upalong.
5.3 The instrument rack should be put inside the boiler as the following diagrammatic
sketch shows.
Fig2
Fig3
Fig4
