Form1 Cycle mode Chart
Sterilize mode, as following
Form 2 Work mode chart
Item
1
2
3
4
5
6
7
8
Digital display Mode Description
Ld Pre-heating
Preparation and conditioning of the
autoclave
HE Heating Chamber is being heated and pressurized
Cycle time Sterilizing Counting down of sterilizing
Dr_ Venting Chamber starts to vent and dry
Drying time Drying Instruments are being dried.
Ed_ Complete
Cycle is complete and chamber door can
be opened
Faults & Error codes Error codes Displays error codes, resets and alarm
LE_ Balance state
When change the state, the pressure of inside
and outside the Autoclave should be the same.
Sterilizing
temperature
Classes
Pre-heating min
Sterilizing time min
Drying time min
Quick drying time
Total time min
Admission time min
Sterilizing pressure
134 121
2.10 1.10
N N
0-7 0-7
5 5
4 16
10 10
1/5 1/5
26(16/20) 38(29/33)
o 134 C o 121 C Clean test
Clean 20
5 5
25
