count Cnt
Controller Cycle
Count AI 39 AI 39 nvoXCtllerCycCnt SNVT_count_inc_f
Controller run time AI 40 AI 40 nvoXCtllerRunTim SNVT_count_inc_f
Lead lag master
status AI 41 AI 41 nvoXLdLgMstrStat SNVT_count_inc_f
Lead lag slave status AI 42 AI 42 nvoXLdLgSlavStat SNVT_count_inc_f
Lead Lag Master
Setpoint Source AI 43 AI 43 nvoXLdLgMstSPSrc SNVT_count_inc_f
Lead Lag Master
Pump Demand AI 44 AI 44 nvoXLdLgMstPpDmd SNVT_count_inc_f
Outdoor
temperature AI 45 AI 45 nvoXOutdoorTmp SNVT_count_inc_f
CH setpoint AV 46 AO 46 nviX/nvoXCH_SP SNVT_count_inc_f
CH TOD setpoint AV 47 AO 47
nviX/nvoXCH_TOD_S
P SNVT_count_inc_f
DHW Demand Switch AV 48 AO 48
nviX/nvoXDHW_Dmd
Switc SNVT_count_inc_f
Outlet high limit
setpoint AV 49 AO 49
nviX/nvoXOutltHiLim
SP SNVT_count_inc_f
Lead Lag setpoint AV 50 AO 50 nviX/nvoXLeadLagSP SNVT_count_inc_f
Leadlag modulation
sensor AV 51 AO 51
nviX/nvoXLdLgModSe
nsr SNVT_count_inc_f
Warm weather
shutdown setpoint AV 52 AO 52
nviX/nvoXWrmWthrS
htSP SNVT_count_inc_f
Lead Lag active
service AI 53 AI 53 nvoXLdLgActSrvc SNVT_count_inc_f
Slave 1 State AI 54 AI 54 nvoXSlv1State SNVT_count_inc_f
Slave 1 firing rate AI 55 AI 55 nvoXSlv1FirRat SNVT_count_inc_f
Slave 2 State AI 56 AI 56 nvoXSlv2State SNVT_count_inc_f
Slave 2 firing rate AI 57 AI 57 nvoXSlv2FirRat SNVT_count_inc_f
Slave 3 State AI 58 AI 58 nvoXSlv3State SNVT_count_inc_f
Slave 3 firing rate AI 59 AI 59 nvoXSlv3FirRat SNVT_count_inc_f
Slave 4 State AI 60 AI 60 nvoXSlv4State SNVT_count_inc_f
Slave 4 firing rate AI 61 AI 61 nvoXSlv4FirRat SNVT_count_inc_f
Slave 5 State AI 62 AI 62 nvoXSlv5State SNVT_count_inc_f
Slave 5 firing rate AI 63 AI 63 nvoXSlv5FirRat SNVT_count_inc_f
Slave 6 State AI 64 AI 64 nvoXSlv6State SNVT_count_inc_f
Slave 6 firing rate AI 65 AI 65 nvoXSlv6FirRat SNVT_count_inc_f
Slave 7 State AI 66 AI 66 nvoXSlv7State SNVT_count_inc_f
Slave 7 firing rate AI 67 AI 67 nvoXSlv7FirRat SNVT_count_inc_f
Slave 8 State AI 68 AI 68 nvoXSlv8State SNVT_count_inc_f
Slave 8 firing rate AI 69 AI 69 nvoXSlv8FirRat SNVT_count_inc_f
Master firing rate AI 70 AI 70 nvoXMstrFirRat SNVT_count_inc_f
