ENGLISH
Chapter 4: Using the DVR
34
DVR User’s Manual
4.1.2 Output Settings (4-Channel/8-Channel)
1
In the preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > DISPLAY, then select the Output tab.
3
Modify the necessary settings:
Menu item Description
Rotate Time Set the interval time (in seconds) when changing screen display in Rotate mode.
See
“3.4.4 Rotate View” on page 29 .
VGA Resolution Select the output resolution.
Init. DEV
(Initial Device) Select where you want to display the OSD menu when multiple monitors are
connected to the DVR (Video Out, VGA, or Auto).
Transparency Hide or display the recording time while recording.
Volume Click Volume, then drag the slider bar to adjust the output volume or select MUTE
to mute the audio.
4
After all settings are complete, click Apply.
5
When data saving is complete, click OK.
4.1.3 Output Settings (16-Channel)
Setting LIVE-OUT or SPOT-OUT
This LIVE-OUT and SPOT-OUT functions allow you to set the number of channels displayed in split mode and order the
display sequence of channels.
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > DISPLAY, then select the Output tab.
3
Modify the necessary settings:
