CY62167EV30 MoBL
®
Document #: 38-05446 Rev. *E
Page 5 of 14
Switching Characteristics
Over the Operating Range
Parameter
Description
45 ns (Industrial/Auto-A)
Unit
Min
Max
READ CYCLE
t
RC
Read Cycle Time
45
ns
t
AA
Address to Data Valid
45
ns
t
OHA
Data Hold from Address Change
10
ns
t
ACE
CE
1
LOW and CE
2
HIGH to Data Valid
45
ns
t
DOE
OE LOW to Data Valid
22
ns
t
LZOE
OE LOW to LOW Z
5
ns
t
HZOE
OE HIGH to High Z
18
ns
t
LZCE
CE
1
LOW and CE
2
HIGH to Low Z
10
ns
t
HZCE
CE
1
HIGH and CE
2
LOW to High Z
18
ns
t
PU
CE
1
LOW and CE
2
HIGH to Power Up
0
ns
t
PD
CE
1
HIGH and CE
2
LOW to Power Down
45
ns
t
DBE
BLE / BHE LOW to Data Valid
45
ns
t
LZBE
BLE / BHE LOW to Low Z
10
ns
t
HZBE
BLE / BHE HIGH to HIGH Z
18
ns
WRITE CYCLE
t
WC
Write Cycle Time
45
ns
t
SCE
CE
1
LOW and CE
2
HIGH
to Write End
35
ns
t
AW
Address Setup to Write End
35
ns
t
HA
Address Hold from Write End
0
ns
t
SA
Address Setup to Write Start
0
ns
t
PWE
WE Pulse Width
35
ns
t
BW
BLE / BHE LOW to Write End
35
ns
t
SD
Data Setup to Write End
25
ns
t
HD
Data Hold from Write End
0
ns
t
HZWE
WE LOW to High-Z
18
ns
t
LZWE
WE HIGH to Low-Z
10
ns
Notes
14. Test conditions for all parameters other than tri-state parameters assume signal transition time of 1 V/ns, timing reference levels of V
CC
(typ)/2, input pulse levels of 0
to V
CC
(typ), and output loading of the specified I
OL
/I
OH
as shown in
“AC Test Loads and Waveforms” on page 4
.
15. AC timing parameters are subject to byte enable signals (BHE or BLE) not switching when chip is disabled. See
for further clarification.
16. At any temperature and voltage condition, t
HZCE
is less than t
LZCE
, t
HZBE
is less than t
LZBE
, t
HZOE
is less than t
LZOE
, and t
HZWE
is less than t
LZWE
for any device.
17. t
HZOE
, t
HZCE
, t
HZBE
, and t
HZWE
transitions are measured when the outputs enter a high impedance state.
18. The internal write time of the memory is defined by the overlap of WE, CE
1
= V
IL
, BHE or BLE or both = V
IL
, and CE
2
= V
IH
. All signals must be ACTIVE to initiate a
write and any of these signals can terminate a write by going INACTIVE. The data input setup and hold timing must refer to the edge of the signal that terminates the write.
