CY62167EV30 MoBL
®
Document #: 38-05446 Rev. *E Page 12 of 14
Figure 13. 48-Pin TSOP I (12 mm x 18.4 mm x 1.0 mm), 51-85183
Package Diagrams
(continued)
1 N
0.020[0.50]
0.007[0.17]
0.037[0.95]
0.002[0.05]
0°-5°
MAX.
0.028[0.70]
0.010[0.25] 0.004[0.10]
0.011[0.27]
0.041[1.05]
0.047[1.20]
0.472[12.00]
0.724 [18.40]
0.787[20.00]
0.006[0.15]
TYP.
0.020[0.50]
0.008[0.21]
GAUGE PLANE
SEATING
PLANE
0.004[0.10]
DIMENSIONS IN INCHES[MM] MIN.
MAX.
JEDEC # MO-142
51-85183-*A
