92 user’s guide
1 Remove any diskette or optical disc (CD or DVD) from the PC.
2 Click the Start button, and then click Turn Off Computer. Click Turn Off to
turn the PC off.
3 Disconnect the modem/telephone cable, if present.
4 Disconnect the power cord from the electrical outlet (1) and then from
the PC (2).
disconnecting the power cord
WARNING: To reduce the risk of personal injury from electrical
shock and/or hot surfaces, disconnect the power cord from the
wall outlet, and allow the internal system components to cool
before touching.
5 Disconnect all external devices connected to the PC.
6 Lay the PC on its side with the access panel (the side with the pull grip)
facing up.
7 Remove the access panel by loosening the screw(s) (1) that secure the access
panel to the PC chassis. Slide the access panel back (2) about 1 inch (2.5 cm),
and then lift it up and off the unit.
removing the pc access panel on the S0000 series model
