working with sound, pictures, and video 51
using the 7-in-1 memory card reader
NOTE: CompactFlash and Microdrive are keyed and cannot be inserted
incorrectly. Insert the receptacle edge (holes) of this media into the slot.
1 Insert the media into the card slot until it stops. The in-use light (A) on the
card reader lights, and the PC automatically detects the media.
2 The PC opens a window so you can use the media contents. You can copy files
from or to the media.
3 When you are done, right-click the drive icon, select Eject, check that the in-
use light is on but not blinking, and then remove the media. A steady light
indicates that the PC is not reading or writing the media.
WARNING: Do not try to remove media when the In-use light is
blinking. Doing so may cause loss of data.
4-slot memory card reader
A
E
D B
C
Card Insert Into 4-slot reader
CompactFlash type I media Receptacle edge (holes) C (lower left)
CompactFlash type II media Receptacle edge (holes) C (lower left)
IBM Microdrive disk drive Receptacle edge (holes) C (lower left)
Secure Digital (SD) Memory Card Facing up D (upper right)
MultiMediaCard (MMC) Facing up D (upper right)
Memory Stick (MS) Memory Card Facing up E (lower right)
SmartMedia (SM) Memory Card Facing up B (upper left)
A In-use light
B Upper left slot
C Lower left slot
D Upper right slot
E Lower right slot
