setting up your pc 7
pc front
The front of your computer has the drives, the On button and hard disk
drive activity indicator light. Some PC models also have connectors on the
front of the PC.
IN IN
G H K L
A
B
C
E
F
D
connecting the modem
The modem is used for connecting to an ISP that provides telephone dial-up
connection to the Internet.
NOTE: Your PC may not come with a modem.
Your PC features and
connector positions
may vary.
A Top optical drive
B Second optical drive
C Diskette (floppy) drive
D On light
E On button
F Hard disk drive
activity indicator light
G FireWire (IEEE 1394)
H Audio in
K USB 2.0 (two shown)
L Microphone
