Using LANVIEW
4-2 Troubleshooting
Table 4-1 provides the definitions of the LED states that occur when the LED mode switch is in the
UP position. Table 4-2 provides the definitions of the LED states that occur when the LED mode
switch is in the DOWN position.
NOTE
The LED mode switch does not change the function of any LEDs on an HSIM or VHSIM
installed in the 6H253-13.
The default switch setting is the RX-TX (up) position.
