TruVision 360° Camera Configuration Manual 41
Name Description
4. Playback button Click to open the Playback window.
5. Control playback Click to control how the selected file is played back: play, stop,
slow and fast forward playback.
6. Audio control Modify the audio level.
7. Time moment Vertical bar shows where you are in the playback recording. The
current time and date are also displayed.
8. Multiview
9. Recording type The color code displays the recording type. Recording types are
schedule recording, alarms recording and manual recording.
The recording type name is also displayed in the current status
window.
10. Zoom in/out Click to zoom in or out of the timeline bar.
11. Archive functions Click these buttons for the following archive actions:
Capture a snapshot image of the playback video.
Start/Stop clipping video files.
12. Download functions
Download video files.
Download captured images.
13. Set playback time Input the time and click to locate the playback point.
To play back recorded video
1. Select the date and click the Search button. The searched video is displayed in the
timeline.
2. Click Play to start playback. While playing back a video, the timeline bar displays
the type and time of the recording. The timeline can be manually scrolled using the
mouse.
Note: You must have playback permission to playback recorded images. See
“Modifying user information” on page 35 to archive recorded video files.
3. Select the date and click the Search button to search for the required recorded file.
4. Click to search the video file.
5. In the pop-up window, check the box of the video file and click Download to
download the video files.
To archive a recorded video segment during playback:
1. While playing back a recorded file, click to start clipping. Click it again to stop
clipping. A video segment is created.
2. Repeat step 1 to create additional segments. The video segments are saved on
your computer.
