circuitry cannot return to its original reference levels, then
either the detector is still masked or possibly has been
damaged. The owner should then visually check that the
detector is still fully functional.
On: Resets the AM or TF status 40 seconds after a PIR alarm.
Off: Resets the AM or TF status after a PIR alarm when the
system is in Day and Walk Test status. The yellow LED will
blink quickly. When the system is in Night status, the yellow
LED will turn off and the system is reset (default).
SW 4: Signaling AM or TF output
On: Signals AM on both the AM and Alarm relays. Signals TF
on the AM relay only (EN 50131).
Off: Signals AM and TF on the AM relay (default).
SW 5: Setting LEDs
On: Enables both LEDs on the detector at all times (default).
Off: Puts both LEDs under the control of the Walk Test and
Day/Night input. This activates the memory feature of the
detector.
Configuring the coverage pattern
• Remove blinders (Figure 8, item 1) if necessary. The
modified pattern is shown in Figure 8, items 3 to 7.
Note: If both blinders are installed, the detector range is
limited to 6 m (default).
• Modify the pattern by breaking out blinder parts (shown as
gray in Figure 8, item 1). The corresponding curtain
fragments are shown in Figure 8, item 2.
• Put the appropriate mirror stickers if necessary. See
Figure 6, item 1 for details.
Caution: Removing stickers can damage the mirror
surface.
• When near objects directly under the detector, fit the mask
to the inside of the window (default). This disables the part
of the curtains looking down at the object, whose
closeness might destabilize the detector. See Figure 6,
item 2.
LED indication
PIR Red LED Alarm relay To reset
Start up Closed Automatically after 25 s
Low voltage Open (Alarm) Apply correct voltage
PIR intruder
alarm Open (Alarm) Automatically after 3 s
PIR/AM Red
LED
Yellow
LED Alarm
relay AM
relay To reset
Start up Closed Closed Automatically
after 60 s
Low voltage Open
(Alarm) Open
(Alarm) Apply correct
voltage
PIR intruder
alarm Open
(Alarm) Automatically
after 3 s
Latched PIR
(Memory) Switch to Night
mode
PIR/AM Red
LED
Yellow
LED Alarm
relay AM
relay To reset
AM alarm Open*
(Alarm) Open
(Alarm) See DIP
switch 3
After AM
reset Switch to Night
mode
Technical
fault Open
(Alarm)
Do a successful
walk test
* Depends on the setting of the DIP switch SW4.
Continuously on Normal blinking (1 Hz) Fast (4 Hz)
Specifications
EV1012 EV1012AM
Detector PIR PIR + AM
Signal processing DSP
Range 12 m
Optical 9 high-density mirror curtains
Memory No Yes
Input power
For UL/cUL installations 9 to 15 V (12 V nominal)
10 to 15 V (12 V nominal)
Peak-to-peak ripple 2 V (at 12 V )
Detector start-up time 25 s 60 s
Normal current
consumption
For UL/cUL installations 4.4 mA
0.0528 W
10 mA
—
Current consumption in
alarm 1.2 mA 3.8 mA
Maximum current
consumption 11 mA 24 mA
Mounting height 1.8 m to 3.0 m (5.90 ft. to 9.84 ft.)
Target speed range 30 cm/s to 3 m/s
(1 ft./s to 10 ft./s)
20 cm/s to 3 m/s
(8 in./s to 10 ft./s)
Alarm (NC) / Tamper
relay characteristic 80 mA
30 V , resistive
80 mA
30 V
Pry-off tamper (not
evaluated by UL/cUL) N/A Onboard (yes)
AM relay characteristic — 80 mA at 30 V max.
Alarm time 3 s
Operating temperature
For UL/cUL installations −10 to +55°C (14 to 130°F)
0 to 49°C ( 32 to 120°F )
Dimensions (H x W x D) 108 Ч 60 Ч 46 mm (4.25 Ч 2.36 Ч 1.81 in.)
Relative humidity 95% max. noncondensing
(UL/cUL installations)
Weight 120 g (4.2 oz.) 128 g (4.5 oz.)
IP/IK rating IP30 IK02
Regulatory information
Manufacturer UTC Fire & Security Americas Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN 55112-6943, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
