Appendix A: Reporting codes
64 NX-8V2 Control Panel Installation Manual
Device numbers for reporting expander
troubles
The following tables list the device names and numbers that report for trouble
conditions.
Table 15: Device numbers that report trouble conditions
Device Name Number
Control panel/modules NX-8V2 control panel Device address 0
NX-534E two-way listen in Device address 64
NX-540E operator Device address 40
NX-591E cell interface Device address 76
Hardware expander (NX-216E) Zone 09 (all switches off) Expander number reported 22
Zone 09 (switch 1 on) Expander number reported 23
Zone 17 (switch 2 on) Expander number reported 16
Zone 25 (switch 1 and 2 on) Expander number reported 17
Zone 33 (switch 3 on) Expander number reported 18
Zone 41 (switch 1 and 3 on) Expander number reported 19
Remote power supply for NX-
320E All switches off Device address 84
Switch 1 on Device address 85
Switch 2 on Device address 86
Switch 1 and 2 on Device address 87
Switch 3 on Device address 88
Switch 1 and 3 on Device address 89
Switch 2 and 3 on Device address 90
Switch 1, 2, and 3 on Device address 91
Wireless receivers All switches off Expander number reported 35
Switch 1 on Expander number reported 36
Switch 2 on Expander number reported 37
Switch 1 and 2 on Expander number reported 38
Switch 3 on Expander number reported 39
Switch 1 and 3 on Expander number reported 32
Switch 2 and 3 on Expander number reported 33
Switch 1, 2, and 3 on Expander number reported 34
Output module for NX- Switch 1 and 2 on Device address 24
