UL294 Access control system units
UL365 Police station connected burglar alarms
UL609, CAN/ULC-S303-
M91 Mercantile, police station connect with
basic line security requires NX-003-C
enclosure
UL985, CAN/ULC-S545-
M89 Household fire
UL1023, ORD-C1023-
1974 Household burglary
UL1610 Central station burglar alarm unit
UL1635 Digital alarm communicator system units
UL1637 Home health care signaling
When installing an NX-8V2 in compliance with Underwriters
Laboratories, the following instructions must be observed:
• Initiating and indicating devices must be rated at 11.5 to
12.4 VDC residential, 12.0 VDC commercial.
• Force arming and auto arming must not be enabled.
• For residential fire applications, the indicating devices
shall be a Wheelock 34T-12 or equivalent.
• The listen in feature shall not be enabled.
• The siren/bell test must be enabled. The auxiliary outputs
controlling the audible device require a minimum cutoff
time of 15 minutes for commercial burglary, four minutes
for residential applications, or 30 minutes for commercial
burglary for Canada.
• For residential fire installations, the dynamic battery test
time cannot exceed four hours.
• Ringback must be enabled on UL commercial burglary
installations.
• On commercial burglary installations, the fire initiating
circuits must not be connected.
• The entry guard feature must be disabled.
• Group bypassing must be disabled.
• Delay before dial seizure must be set to 0.
• Total current draw from auxiliary power connections at
terminal positions POS, AUX PWR, and SMOKE PWR
must not exceed 400 mA.
• Remote downloading must not be used on UL listed
systems.
• For residential burglary applications, the maximum entry
and exit delay times are 45 and 60 seconds respectively.
The exit delay time must not exceed 60 seconds for
commercial burglar alarm applications.
• The keyswitch option must not be used.
• The telephone line monitor must be enabled.
• The telephone line cut delay must not exceed 90 seconds.
• The 24-hour communicator test transmission is required.
• For 24-hours of standby power using a 7.0 Ah battery, limit
auxiliary power load to 140 mA.
• For 24-hours of standby power using a 17.2 Ah battery,
limit auxiliary power load to 400 mA.
• The silent keypad option must not be enabled.
• UL has only verified compatibility with the following listed
DACRs and formats: Sure-Gard SG-MLR2-DG:
2,9,10,12,13,14; Silent Knight 9000 - 2,12; FBI -
CP220FBI, 13; and Ademco 685: 2,11,12, and 13.
• For burglary installations, cross zoned detectors must
overlap 100 percent in the area of coverage, and similar
coverage areas must be used. For example, interior
protection is cross zoned with interior protection, and so
on.
• Expander trouble must activate the siren.
• For UL 1637, expander trouble must activate the keypad
sounder.
• If the late to close/early to open feature is enabled, the
opening and closing reports must be enabled.
• For Canadian installations, the class II transformer secure
tab must not be employed.
• The four-wire smoke detector employed must be rated to
operate over the voltage range of 11.5 to 12.4 V.
• Compatible listed devices: (special applications):
• Bell output (sirens): Wheelock models: NS-1215W,
NS-121575W, NS4-1215W, NS4-121575W, AS-1215W,
AS-121575W
• Horn/strobe system sensor: S1224MC strobe series;
1224MC Horn/strobe series; H12/24 Horn series
• Smoke output (four-wire detectors): ESL: 500N
series; 449CTE series; 521 series; 541 series
• System sensor models: 2112/24R; 2112/24TR;
2112/24AT; 2112/ATR; 2112/24AITR; 4WTA-B; 4WTR-B;
4WTAR-B; 4WITAR-B
• Detection systems: F220-B6C; D273 series; Hochiki:
SBC-4/12, 4/12W
Additional UL 609 installation requirements
The alarm housing for a mercantile alarm system without a
remote alarm transmission connection shall be mounted on the
outside of the building, visible from a public street or highway.
It shall be accessible for examination and repair. It shall also
be located not more than four stories above the street level
unless:
a) A second alarm sounding device and housing, intended for
outside service is mounted adjacent to the premises or area of
the building in which the alarm system is installed or
b) A second alarm sounding device, intended for inside service
is mounted within the premises.
In either case, the outside alarm sounding device and housing
may be mounted as high as the seventh floor.
Additional UL 365 installation requirements
In a mercantile burglar alarm system, a mercantile alarm
sounding device located within a building, but outside the
