Segment 2 - Phone 1 backup control
Program the backup control for phone 1. The default is 0.
• Program a 0 in segment 2 to cause the NX-8V2 to make
the designated number of attempts to phone 2 before
setting the fail to communicate condition to stop reporting.
• Program a 1 in segment 2 to cause the NX-8V2 to stop
trying to communicate after the designated number of
attempts have been made to phone 1.
• Program a 2 in segment 2 to cause the NX-8V2 to make
the dial attempts in increments of two. The first two
attempts are made to phone 1, the next two attempts to
phone 2. This repeats until the total number of attempts
designated in segment 1 is completed.
Location 4 - Phone 1 events reported
Location 4 has two segments of feature selection data. Use
this location to select those events reported to phone 1.
• If you do not want dual or split reporting, use Location 4 to
select all events to phone 1.
• If you want dual or split reporting and the split is based on
the event type (alarm, open/close, etc.), use Location 4 to
select only those events that are reported to phone 1.
• If you don’t want events reported to phone 1, program 0 in
Location 4 (disabling all options).
Segment 1
1. Alarms and alarm restores.
2. Opening and closings.
3. Zone bypass and bypass restores.
4. Zone trouble and trouble restores.
5. Power fail, low battery, power restore, and low battery
restore.
6. Bell cut, telephone line cut, bell cut restore, telephone line
restore.
7. Test reports.
8. Start and end programming, download complete.
Segment 2
1. Zone and box tamper and tamper restore.
2. Auxiliary power overcurrent, ground fault, and restore for
both.
3. Wireless sensor missing and restore.
4. Wireless sensor low battery and restore.
5. Expander trouble and restore.
6. Fail to communicate.
7. Zone activity monitor.
8. Reserved
Location 18 - Custom communicator format
Location 18 has four segments of feature selection data. Use
this location to program the communicator format used to
transmit to the receiver connected to phone 3. Refer to your
central station receiver documentation to determine which
format is compatible. Select a format from Table 4 on page 4. If
you need a format other than those listed, review the override
options described in this location to build the appropriate
format.
Segment 1
1. On for 1800 Hz transmit; off for 1900 Hz.
2. On for 2300 Hz handshake; off for 1400 Hz.
3. On for cksum parity; off for double round parity.
4. On for two-digit event code; off for one-digit event code.
5. Reserved.
6. Reserved.
7. On for 20 pps; off for 10 or 40 pps.
8. On for 10 pps; off for 20 or 40 pps.
Segment 2
1. On for pager format (no handshake required).
2. On for 1400/2300 handshake.
3. Reserved.
4. Reserved.
5. On for contact ID.
6. On for SIA.
7. On for contact ID or 4+3.
8. On for DTMF.
Segments 3 and 4 - Reserved
Location 25 - Zones 1 to 8 zone type
Location 25 has eight segments of numerical data. Use this
location to program the zone type for zones 1 to 8. Use
segment 1 for zone 1, segment 2 for zone 2, etc. The segment
defaults are 3, 5, 6, 6, 6, 6, 6, 6.
Zones are programmed to be one of thirty different types. Use
zone types 17 through 20 for wireless, or for hardwired zones
using European double EOL configuration
Table 5 below describes the zone types.
Table 5: Zone types
Zone type Description
1. Day zone This zone is instant when the system is armed;
trouble zone when the system is disarmed.
