Location 0 - Phone 1
Location 0 has 20 segments of numerical data. Use this
location to program phone 1. The default for each segment is
14.
• To program a delay of four seconds, enter 13 in the
appropriate segment.
• To program tone dialing, enter 15 in the segment where
tone dialing begins.
• If the entire number is tone dialing, enter 15 in the first
segment.
• Enter 11 for a *, and 12 for a #.
Caution: A call-waiting cancel on a non call-waiting line
prevents successful connection to the central station.
Location 1 - Phone 1 account code
Location 1 has six segments of numerical data. Use this
location to program the account code sent when phone 1 is
dialed. The default for each segment is 10. Program a 10 in the
segment immediately after the last digit of the account code. If
the account code is six digits long, program all six segments.
Location 2 - Phone 1 communicator format
Location 2 has one segment of numerical data. Use this
location to program the communicator format used to transmit
to the receiver connected to phone 1. Refer to your central
station receiver documentation to determine which format is
compatible. Table 4 below describes the formats for this
location. If you need a format other than those listed, review
the override options described in “Location 18 - Custom
communicator format” on page 5 to build the appropriate
format. Program a 15 to create a special format (in addition to
the entries in Location 18). The default is 0. If this location
contains a 0, the built-in communicator is disabled and the NX-
8V2 functions as a local-only control.
Table 4: Communicator formats
Data Format Description
0 Local Communicator is disabled
1 Universal 4+2 Two-digit event code 1800 Hz transmit
2300 Hz handshake double round parity
40 pps
a
2 3+1 fast (or 4+1) One-digit event code 1900 Hz transmit
1400 Hz handshake double round parity
20 pps
3 Reserved Reserved
4 Pager Two-digit event code DTMF
transmission
Data Format Description
5 3/1 or 4/1 slow 1800 Hz transmit 2300 Hz handshake
double round parity 20 pps hex
capability
6 3/1 or 4/1 slow 1800 Hz transmit 1400 Hz handshake
double round parity 20 pps hex
capability
7 3/1 or 4/1 fast 1800 Hz transmit 2300 Hz handshake
double round parity 40 pps hex
capability
8 3/1 or 4/1 fast 1800 Hz transmit 1400 Hz handshake
double round parity 40 pps hex
capability
9 3/1 or 4/1 fast with
parity 1800 Hz transmit 2300 Hz handshake
single round parity 40 pps hex capability
10 3/1 or 4/1 fast with
parity 1800 Hz transmit 1400 Hz handshake
single round parity 40 pps hex capability
11 4+2 express Two-digit event code DTMF
transmission
12 4+2 fast Two-digit event code 1900 Hz transmit
1400 Hz handshake double round parity
20 pps
13 Ademco contact ID DTMF
14 SIA Frequency shift keys
15 Custom format See “Location 18 - Custom
communicator format” on page 5
16 3/1 or 4/1 slow Same as 5, but sends the alarm event
code rather than the zone number
17 3/1 or 4/1 slow Same as 6, but sends the alarm event
code rather than the zone number
18 3/1 or 4/1 fast Same as 7, but sends the alarm event
code rather than the zone number
19 3/1 or 4/1 fast Same as 8, but sends the alarm event
code rather than the zone number
20 3/1 or 4/1 fast with
parity Same as 9, but sends the alarm event
code rather than the zone number
21 3/1 or 4/1 fast with
parity Same as 10, but sends the alarm event
code rather than the zone number
22 SIA SIA with area modifiers
a> Pulses per second.
Location 3 - Phone 1 dial attempts/backup control
Location 3 has two segments of numerical data.
Segment 1 - Phone 1 dial attempts
Program the number of dial attempts (1 to 15) the
communicator makes to phone 1 before ending the notification
process. The default is 8, which means that the communicator
makes eight attempts to the first number.
4 NX-8V2 Control Panel Installation Instructions
