3-19
Interactive Mode
The Module Specific Screen
Select a module on the Module Selection Screen, as shown in Figure 3-23, to
display configuration information on the Module Specific Screen, as shown in
Figure 3-24.
Line 1 identifies the selected module by chassis slot location, current status, and
hardware revision. A module’s status can be one of the following:
ON-LINE The host processor is operational.
DOWN The host processor is not operational.
FAULT The power-up diagnostic tests have failed.
Lines 2 and 3 display a firmware revision and SMB-1 firmware revision, along
with the BOOT PROM revision and the module serial number.
Line 4 lists the following three submenus. Access a specific submenu by selecting
it on the screen.
accesses the Module Environment Screen, showing
environmental parameters for the selected module.
accesses the Module Memory Screen, showing the amount of
various memory categories on the module.
accesses the Module Backplane Screen, showing backplane
configuration parameters.
Figure 3-24. The Module Specific Screen
Select to return to the Module Selection Screen.
FW REV x.xx.xx SMB 1 FW REV x.xx.xx
MODULE xx STATUS ON-LINE HW REV xxx
BOOT PROM REV x.xx.xx SN xxxxxxxxxxxx
