9C300-1 Environmental Module Operation
3-12
Interactive Mode
The LCD enters this mode upon installation. This mode allows user input
through the five-function keypad to navigate through MMAC-Plus status screens,
and to make menu selections.
Press any button on the keypad to enter this mode from the non-interactive mode.
Once past the Main screen, the Interactive Mode is maintained for three minutes
without a keypad entry before returning to the non-interactive mode.
Interactive Mode Screens
This section describes the LCD screens that display in the Interactive Mode. The
Interactive Mode screen flow, as shown in Figure 3-12, provides a representation
of the Interactive Mode screen structure hierarchy.
Figure 3-12. Interactive Mode Screen Flow
Main Screen
System
Pwr
Environment Diag Com BBU
Alarms Modules
Modules Selection Screen
Modules/Environmental Module Specific Screen
Environment Memory Backplane
Screen Contrast
Screen Adjust
Supply
Specific
Results
Pwr
