9C300-1 Environmental Module Operation
3-14
Select after reading all alarms to reset the front panel
ALARM LED (red to green). Selecting deletes all alarms
and resets the alarm pending banner on line 4 of the non-interactive screens.
Select to return to the Main Screen.
The System Screen
Select the option field in line 4 of the Main Screen, as shown in
Figure 3-13, to access the System Screen as shown in Figure 3-15. This screen
displays information specific to the MMAC-Plus chassis. Lines 1 and 2 display the
MMAC-Plus chassis Internet Protocol (IP) address and Media Access Control
(MAC) address.
Line 3 displays the current chassis hardware revision and serial number.
Line 4 lists the following five submenus. Access a specific submenu by selecting it
on the screen.
Displays general power supply configuration information,
with the option to view statistics on specific power supply
modules.
Displays environmental information about the chassis.
Displays statistics and information about the front panel
COM ports and EPIM on the Environmental Module.
Displays the results of power-up or restart diagnostic tests.
Displays status of BBUs, if they are installed.
Figure 3-15. The System Screen
Select to return to the Main Screen.
CHASSIS MAC ADDRESS xx-xx-xx-xx-xx-xx
CHASSIS HW REV xxx SN xxxxxxxxxxxx
CHASSIS IP ADDRESS xxx.xxx.xxx.xxx
