IFS MCR200-1T/1CX User Manual 5
LED Indicators
System
LED
Color
Function
On
Power ON
PWR
Green
Off
Power OFF
VDSL
LED
Color
Function
On
Indicates that the VDSL link is established.
Fast
Blinking
Indicates that the VDSL link is at training
status (about 10 seconds).
LNK/ACT
Green
Slow
Blinking
Indicates that the VDSL link is at idle status.
CO
Green
On
Indicates the VDSL Bridge is running at CO
mode.
CPE
Green
On
Indicates the VDSL Bridge is running at CPE
mode.
10/100Base-TX Port
LED
Color
Function
On
Indicates that the port link is On.
Blinking
Indicates that the Converter is actively
sending or receiving data over that port.
LNK/ACT
Green
Off
Indicates that the port link is Off.
On
Indicates that the port is operating at
100Mbps.
100
Green
Off
Indicates that the port is off or operating at
10Mbps.
Rear Panel
The units’ rear panel provides a simple interface for monitoring
the MCR200-1T/1CX.
