8
Video
Record
Speed
PAL：1f/s～12.5f/s.
NTSC：1f/s～15f/s
(Now it max supports
12.5f/s. )
UXGA/WSXGA/SXGA/
WXGA/XVGA:
1f/s to 15f/s per
channel(adjustable)
Other resolutions:
PAL：1f/s-25f/s per
channel (adjustable).
NTSC：1f/s-30f/s per
channel (adjustable).
1.3M resolution:
PAL：1f/s-12f/s per
channel (adjustable).
NTSC：1f/s-22f/s
per channel
(adjustable).
Other resolutions:
PAL：1f/s-25f/s per
channel (adjustable).
NTSC：1f/s-30f/s
per channel
(adjustable).
PAL：1f/s-25f/s per
channel (adjustable).
NTSC：1f/s-30f/s per
channel (adjustable).
Network Capacity
Max support 10 network users to monitor simultaneously
TCP output capacity 75Mbps
UDP output capacity 85Mbps
Power Consumption
Usually it is 4W and
the max value is less
than 5W.
Usually it is 3W and the max value is less than 4W.
DC 12V
Power
PoE（48V DC）
Working environment temperature：-10℃～50℃
Temperature Chassis internal rising temperature is less than 20℃（When IPC is working ,the chassis internal
temperature deducts environment original temperature.）
Working
Environment
Humidify
10%～90％
Dimension(H*W*D） 58mm*69mm*139mm
Weight
500g
1.3.2 Function Specification
Please refer to the following sheet for function specification information.
Note
Specification
F725 F715 F6X5 F726
Zoom Adjustment Manual
Focus Adjustment Manual
Lens Control
Aperture Adjustment Manual DC
Manual/Auto
DC Manual/Auto
DC
N/A
Backlight compensation
control
Manual On/Off
White balance
adjustment
Auto
Contrast ness adjustment Manual/Auto
Bright ness adjustment
Manual/Auto
Electronic shutter control Auto Manual/Auto Manual/Auto Auto
CCD Video
Process
Color/B&W(Day/Night)
switch
Manual/Auto
Note
The color/B&W (Day/Night) switch here just an electronic switch.
System removes the color elements and reserves the B&W
elements. It is not a filter switch.
Video
Resolution
UXGA、WSXGA、
SXGA、WXGA、
XVGA、SVGA、 1.3M、720、
VGA、
QVGA、D1、 D1、BCIF、
HD1、CIF、
QVGA、
UXGA、
D1、
HD1、CIF、
