IC Realtime 540TVL Box Style IP Cameras (ICIPS565) User Manual
Page 18
18
LEVEL Auto
aperture
adjustment button
Adjust aperture level.
(For F715 and F6X5
series only)
Please always use
nonmetal material tool
to adjust.
IR Infrared
remote
receiver
Receive the IR signal
from the remote
control.
(This function does
not apply to F725
series product.)
AUDIO OUT
Audio output port
Audio output 3.5mm
JACK port.
Output audio signal to
the device such as
sound box.
AUDIO IN
Audio input port
Audio input 3.5mm
JACK port.
Input audio signal.
Receive signals from
devices such as pick-
up.
LAN
Ethernet port
Connect to standard
Ethernet cable.
SD
SD card port
Connect to SD card.
Note
z
When you install
the SD card,
please make sure
current card is not
in write mode and
then you can
install it to the
camera.
z
When
you
remove the SD
card, please
