IC Realtime 540TVL Box Style IP Cameras (ICIPS565) - Manual (Page 21)

21
Reserved Reserved for future use
Record Reserved for future use
Alarm arm Reserved for future use
Alarm disarm Reserved for future use
Go to safe mode
Exit safe mode Reserved for future use
Number switch/Function switch
Number switch/Function switch
Go to the previous
Direction buttons
Go to the next
Confirm/Menu
button
Go to the menu or confirm current
operation.
Cancel Cancel current setup
～
Number 0 to
number 9
Number/password/channel switch
For number more
than 10+
Reserved
Input method switch Reserved
2.5 Bidirectional talk
2.5.1 Device-end to PC-end
Device Connection
Please connect the speaker or the pickup to the first audio input port in the device rear panel.
Then connect the earphone or the sound box to the audio output port in the PC.
Login the Web and then enable the corresponding channel real-time monitor.
Please refer to the following interface to enable bidirectional talk.
