All the figurers listed below are for reference only. Slight difference may be found on the
front or rear panel.

Important:
If the HDD amount is less than four, you do not need to install the HDD bracket.
When there is a bracket, please make sure the installation direction of HDDs is the same.

3.4 Rack Installation

Please note this installation mode is for 1.5U/2U series product.
Please follow the steps listed below.
z

Use twelve screws to fix the unit

z

Please make sure the indoor temperature is below 35℃ (95°f).

z

Please make sure there is 15cm (6 inches) space around the device to guarantee sound

ventilation.

z

Please install from the bottom to the top.

z

If there are more accessories connected in the rack, please take precaution measures in

case the rack power is overload.

3.5 Connecting Power Supply

Please check input voltage and device power button match or not.
We recommend you use UPS to guarantee steady operation, DVR life span, and other peripheral
equipments operation such as cameras.

3.6 Connecting Video Input and Output Devices

3.6.1 Connecting Video Input

The video input interface is BNC. The input video format includes: PAL/NTSC BNC(1.0V

B

P- P

B

75Ω.)
The video signal should comply with your national standards.
The input video signal shall have high SNR, low distortion; low interference, natural color and
suitable lightness.
Guarantee the stability and reliability of the camera signal:
The camera shall be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
The camera and the DVR should have the same grounding to ensure the normal operation of the
camera.
Guarantee stability and reliability of the transmission line

BTTTB

Please use high quality, sound shielded BNC. Please select suitable BNC model according to the
transmission distance.

7. Unfasten the HDD power

cable.


9.

Use the special data cable to

connect the HDD and the SATA

port. Close the chassis and fix

the screws to secure firmly.

8.

Insert the HDD power

cable.
