133
Parameter Function
clicking OK button to save your motion detection zone setup.
Record
channel System auto activates motion detection channel(s) to record once
an alarm occurs. Please note you need to set motion detect
record period and go to Storage-> Schedule to set current
channel as schedule record.
Record Delay System can delay the record for specified time after alarm ended.
The value ranges from 10s to 300s.
Alarm out Enable alarm activation function. You need to select alarm output
port so that system can activate corresponding alarm device when
an alarm occurs.
Latch
System can delay the alarm output for specified time after an
alarm ended. The value ranges from 1s to 300s.
Show
message System can pop up a message to alarm you in the local host
screen if you enabled this function.
Buzzer Check the box here to enable this function. The buzzer beeps
when an alarm occurs.
Alarm upload System can upload the alarm signal to the centre (Including alarm
centre.
Message When 3G network connection is OK, system can send out a
message when motion detect occurs.
Send Email If you enabled this function, System can send out an email to alert
you when an alarm occurs.
Tour You need to check the box here to enable this function. System
begins 1-wiindow or multiple-window tour display among the
channel(s) you set to record when an alarm occurs.
Please go to chapter 5.3.9 to set tour interval and tour mode.
PTZ
Activation Here you can set PTZ movement when alarm occurs. Such as go
to preset X. See Figure 7-40.
Video Matrix This function is for motion detect only. Check the box here to
enable video matrix function. Right now system supports one-
channel tour function. System takes “first come and first serve”
principle to deal with the activated tour. System will process the
new tour when a new alarm occurs after previous alarm ended.
Otherwise it restores the previous output status before the alarm
activation.
7.8.3.1.2 Video Loss
The video loss interface is shown as in Figure 7-41.
After analysis video, system can generate a video loss alarm when the detected moving signal
reached the sensitivity you set here.
Please note video loss does not support anti-dither, sensitivity, region setup. For rest setups,
please refer to chapter 7.8.3.1.1 motion detect for detailed information.
