18
ORDERING PARTS
Replacement parts for the Heli-Max AXE CP V3 RTF are
available using the order numbers in the Parts List on page
18. The fastest, most economical service can be provided by
your hobby dealer.
To locate a hobby dealer, visit the Hobbico web site at www.
hobbico.com. Choose “Where to Buy” at the bottom of the
menu on the left side of the page. Follow the instructions
provided on the page to locate a U.S., Canadian or
International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa® or MasterCard®
number and expiration date for payment.
Mail parts orders and payments by personal check to:
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Be certain to specify the order number exactly as listed in
the Parts List. Payment by credit card or personal check
only; no C.O.D.
If additional assistance is required for any reason contact
Product Support by e-mail at [email protected], or
by telephone at (217) 398-8970.
AXE CP V3 PARTS LIST
# Stock # .......... Description .......................... Includes
1 HMXE7442 .... Canopy White CPv3 ..........................1
2 HMXE8819 .... Battery Rubber Bands .......................3
3 HMXE7426 .... Canopy Grommets.............................2
4 GPMP0401 .... LiPo 111v 950 MHA AXE CPv3 .........1
5 HMXE4703 .... Antenna Tube .....................................1
6 HMXE8605 .... Canopy Mounts..................................3
7 HMXE8901 .... Skids ..................................................2
8 HMXE7342 .... Screw Set ........................................40
9 HMXE8902 .... Skid Supports ....................................2
10 HMXE8407 .... Main Frame ........................................2
11 HMXM2004 ... Servo .................................................1
12 HMXE8814 .... Servo Mounting Screws .....................6
13 HMXE8818 .... Servo Arms w/screws ........................6
14 HMXE9002
.... Swashplate Stay ................................1
15 HMXE9554 .... Tail Motor Extension Wire ..................1
16 HMXE9550
.... Tail Boom ...........................................1
17 HMXE9551 .... Tail Fin Support Rod ..........................1
18 HMXE9562
.... Tail Vertical Fin ...................................1
19 HMXE8623 .... Heat Sinks .........................................2
20 HMXE9553 .... Tail Motor ...........................................1
21 HMXE9564 .... DD Tail Motor Mount ..........................1
# Stock # .......... Description .......................... Includes
22 HMXE9563 .... DD Tail Rotor Blade ...........................1
23 HMXE9556 .... Tail Motor Screws ..............................2
24 HMXE9561 .... Tail Vertical Fin Bracket w/screws ......3
25 HMXE7301 .... Replacement Bearing Set ..................8
26 HMXE8405 .... Main Shaft Collar and Bushing ..........3
27 HMXE7627
.... Complete Linkage Set (Includes #60) ..7
28 HMXE8406 .... Main Shaft .........................................1
29 HMXE9001 .... Swashplate Assembly ........................1
31 HMXE8319 .... Bell-Hiller Mixing Arms ......................2
32 HMXE7806
.... Feathering Spindle ............................1
33 HMXE8607 .... Center Hub ........................................1
34 HMXE9058 .... Slide Block .........................................1
35 HMXE8606 .... Control Hub Screws ...........................2
36 HMXE8801
.... Seesaw ..............................................1
37 HMXE7804 .... Flybar Paddles ...................................2
38 HMXE8622 .... Head Button .......................................1
39 HMXE8813 .... Stabilizer Control Hub ........................1
40 HMXE7805
.... Flybar Weights ...................................2
41 HMXE8320 .... Bell-Hiller Weights .............................2
42 HMXE7803 .... Flybar .................................................1
43 HMXE8323 .... Bell Hiller Dampening Spacer ............4
44 HMXE8322 .... Reinforced Main Rotor Blades ...........2
45 HMXE8318 .... Bell-Hiller Main Blade Grips ...............2
46 HMXE7362
.... O-Ring Set .........................................4
47 HMXE8621 .... Head Bolt and Nut .............................2
48 HMXE7802
.... Flybar Links .......................................2
50 HMXM2005 ... Receiver.............................................1
51 HMXM2003 ... E-Board (Mixer, Gyro, ESC) ..............1
52 HMXE8002 .... Main Motor, 380 .................................1
59 HMXE8404 .... Main Rotor Gear ................................1
60 HMXE8321 .... Bell-Hiller Linkage Set .......................4
HMXE7511
.... Decal Set .............................................
HMXE9552 .... Training Gear .....................................2
HMXP1004 .... 3s LiPo Balance Charger ...................1
HMXZ7006 .... Instruction Manual .............................1
OPTIONAL PARTS
HMXE7450 ...Carbon Fiber Vertical Fin w/Hardware
HMXE7451 ...Carbon Fiber Horizontal Fin w/Hardware
HMXE7452 ...Carbon Fiber Flybar Paddles .......................
HMXE7453 ...Carbon Fiber Tail Boom ................................
HMXE7454 ...CNC Swashplate Assembly .........................
HMXE7455 ...CNC Center Hub & Head Button ..................
HMXE7456 ...CNC Slide Block & Seesaw ..........................
HMXE7459 ...CNC Bell-Hiller Main Blade Grips ................
HMXE7657 ...CNC Flybar Carrier ......................................
