PROBLEM: The Camera System will not take a photo or start recording
a video.
Solution 1: Install the micro SD card if it is not in the slot.
Solution 2: Eject the card and check for any debris on the contacts.
Solution 3: Make sure card is OK by putting the card in the reader and
checking on your PC.
®
MAINTENANCE MAINTENANCE
The maintenance tips for the 1SQ quadcopter will apply to the V-Cam
quadcopter also. The guide can be found at the WWW.Helimax-rc.com in
the download section with the other 1SQ files.
®
REPLACEMENT PARTS REPLACEMENT PARTS
Key Part No. Description
1 HMXE2211 Canopy White/Black
2 HMXE2210 Rotor Blades
3 HMXE2212 LED Motor Boom Set RF Clockwise
4 HMXE2213 LED Motor Boom Set LR Clockwise
5 HMXE2214 LED Motor Boom Set LF Counter
6 HMXE2215 LED Motor Boom Set RR Counter
7 HMXE2180 Control Board Dampners
8 HMXZ0001 Vcam Vid/Pic Camera
9 HMXE2217 Screw Set
10 HMXE2179 Frame Battery Mount
11 HMXP1009 250mAh LiPo Battery
12 HMXM2052 TAGS-FX Control Board
13 HMXE2183 Foot Pads
HMXJ2000 1SQ V-Cam Transmitter SLT
HMXP2023 USB Charger
HMXZ0002 USB microSD Card Reader
HMXE2184 Motor Cover
