15
SECTION ONE
Getting Started
CHAPTER 1
Haltech F9 Installation
1.1 Overview
The Haltech F9 system comprises the following components
Haltech Electronic Control Unit (ECU)
Coolant Temperature Sensor
Inlet Air Temperature Sensor
Throttle Position Sensor (TPS)
Manifold Absolute Pressure (MAP) Sensor
(1,2 or 3 Bar Sensor - purchased separately to main kit)
Main Wiring Harness
Haltech F9 system Instruction Manual
Programming Cable
Programming Disk
Relays
Optional Items
Fuel Mixture Trim Control
F9A Upgrade Kit with Auxiliary Loom
Optional Items with F9A (Only)
Exhaust Gas Oxygen Sensor
Idle Speed Control Motor
Other components not supplied as part of the F9 system include:
Inlet
Manifold
Throttle body
Throttle linkages
Velocity stacks
Injector Mounts
Fuel injectors
High pressure fuel pumps
Inlet Air Cleaners
Performance ignition systems
Trigger System
