12
Haltech F9 Specifications
Engine Suitability
• up to 16,000 rpm
• 1, 2, 3, 4, 5, 6, 8, 10, 12 cylinders (1-2 rotors)*
• 2 or 4 stroke
• normally aspirated or supercharged up to 200 kPa (30 psi)
• load sensing by throttle position or manifold pressure
• multipoint, batch-fire, staged injection
Power Requirements
• Power Source
8.6 to 16 Volts DC
• Consumption
Haltech ECU: 270 mA at 12 Volts
Injector Load: Dependent on injector type
approx. proportional to injector duty cycle
(typically 0.6 Amps per injector)
Physical Specifications
• ECU Dimensions
Length: 168 mm (6 5/8")
Width: 145 mm (5 5/8")
Depth: 41 mm (1 5/8")
• Weight
ECU:
760g (1.68 lb)
Loom: 1.1kg (2.4 lb)
Sensors: 170g(1.1 lb)
Shipping Weight: 3kg (9.9 lb)
(Including manual/packaging)
Input Sensors
• Manifold Absolute Pressure (MAP) Sensor
1 Bar -100kPa to 0kPa (Naturally Aspirated)
2 Bar -100kPa to 100kPa (up to 1 Bar or 15 psi boost)
3 Bar -100kPa to 200kPa (up to 2 Bar or 30 psi boost)
• Temperature Sensors (Air and Coolant)
NTC temperature dependent resistor type.
Operating Range
Continuous -40°C to 100°C (-40°F to 212°F)
Intermittent up to 125°C (257°F)
