2500 Series 9
Using the Soft Switches to Control the Menu
Three of the switches in bank seven are dedicated to a three-choice menu that may be
used to enable, disable or move the larger command menu. Pick BANK and block number
seven and then SETUP to gain access to these switches.
SWITCH 3
SWITCH 4
SWITCH 5 Locates the lower left corner of the menu at the next point picked on
the active area.
Erases the menu from its current location.
Restores the menu at the location from which it was last erased.
Pick the switch you want. The change will take effect as soon as you select BANK once
more to go back to operating mode.
Enable/Disable Cursor Commands
The 16-button cursor may be used to send commands to the tablet or messages to the
host. This command enables or disables that function without interfering with the use of
the cursor for digitizing. The cursor may disable itself, with the command FF0E, but once
disabled, it must be enabled by a command from the host or menu.
The soft switch settings control whether the cursor commands will be enabled or disabled
at power-up.
Host = ESC % K (b) CR
Menu = [CURSOR FUNC ON/OFF] ([b]) [CR]
Cursor = FF 0 E (disable only)
Where b can equal 0 or 1 or no entry:
If b = 0
If b = 1
If no b is entered Cursor function commands are disabled.
Cursor function commands are enabled.
The condition toggles.
