where the engine torque tends to steer the airplane to
the left.
Retractable Mains/Fixed Tail Wheel: This is the heaviest
and most complex of the three configurations. It is also the
most aerodynamic and the “coolest” by far.
Throughout the manual there are steps named as above
which pertain only to that landing gear configuration. Decide
which landing configuration you want to use and cross out
all steps that are for other landing gear configurations.
Following is the list of hardware and accessories required to
finish the Great Planes Ultra Sport 40 Plus. Order numbers
are provided in parentheses.
❏
Spinner – 2-1/4" (GPMQ4515)
❏
Propellers – see engine manufacturer’s recommendation
❏
Fuel line – 3' [914mm] silicone (GPMQ4131)
❏
10 oz. Fuel tank (GPMA4104)
If you are using a computer radio you will also need:
❏
(2) 6" Servo extensions (HCAM2700)
If you are using a non-computer radio you will also need:
❏
(1) “Y” harness (HCAM2751)
❏
(1) 6" Servo extension (HCAM2700)
If you are building a Fixed Mains and Tail Wheel Landing
Gear Configuration you will also need:
❏
(2) 2-1/2" Main wheels (GPMQ4223)
❏
(1) 1" Tail wheel (GPMQ4241)
❏
(4) 5/32" Wheel collars (GPMQ4306)
❏
(1) 3/32" Wheel collars (GPMQ4302)
If you are building a Fixed Tricycle Landing Gear
Configuration you will also need:
❏
(2) 2-1/2" Main wheels (GPMQ4223)
❏
(1) 2-1/4" Nose wheel (GPMQ4222)
❏
(5) 5/32" Wheel collars (GPMQ4306)
If you are building a Retractable Mains/Fixed Tail Wheel
Landing Gear Configuration you will also need:
❏
(2) 2-1/2" Main wheels (GPMQ4223)
❏
(1) 1" Tail wheel (GPMQ4241)
❏
(2) Great Planes .40-size retractable landing gear (GPMQ2905)
❏
(4) 5/32" Wheel collars (GPMQ4306)
❏
(1) 3/32" Wheel collar (GPMQ4302)
❏
(4) Screw-Lock pushrod connectors (GPMQ3870)
In addition to common household tools (screw drivers, drill,
etc.), this is the “short list” of the most important items
required to build the Great Planes Ultra Sport 40 Plus.
We
recommend Great Planes Pro ™ CA and Epoxy glue.
❏
1/2 oz. Thin Pro CA (GPMR6001)
❏
1 oz. Medium Pro CA+ (GPMR6008)
❏
6-Minute epoxy (GPMR6045)
❏
Latex foam rubber (HCAQ1000)
❏
30-Minute epoxy (GPMR6047)
❏
Hobby knife (HCAR0105)
❏
R/C-56 canopy glue (JOZR5007)
❏
Microballoons (TOPR1090)
❏
#11 Blades (HCAR0211)
❏
Single-edge razor blades (HCAR0212)
❏
Denatured alcohol (for epoxy clean up)
❏
Small T-pins (HCAR5100)
❏
Builder’s triangle (HCAR0480)
❏
Electric drill and 1/16" [1.6mm] [1.6mm], 5/64" [2mm],
3/32" [2.4mm] [2.4mm], 1/8" [3.2mm] [3mm], 9/64"
[3.6mm], 5/32" [4mm],17/64" [6.7mm] and 1/4" [6mm]
drill bits
❏
Small Phillips and flat blade screwdrivers (HCAR1040)
❏
Pliers with wire cutter (HCAR0630)
❏
Great Planes Plan Protector ™ (GPMR6167) or waxed paper
❏
Sanding tools and sandpaper assortment (see “Expert
Tip-Easy-Touch ™ Bar Sander” on page 5)
❏
Great Planes tap and drill set (GPMR8108)
❏
Great Planes 1/4-20 tap and drill set (GPMR8105)
❏
Great Planes Pro Threadlocker ™ (GPMR6060)
Here is a list of optional tools mentioned in the manual that
will help you build the Great Planes Ultra Sport 40 Plus.
❏
Great Planes CG Machine ™ (GPMR2400)
❏
Top Flite ® Precision Magnetic Prop Balancer ™ (TOPQ5700)
❏
Top Flite Hot Sock ™ iron cover (TOPR2175)
❏
Straightedge with scale (HCAR0475)
❏
Cutting mat (HCAR0456)
❏
Masking tape (TOPR8018)
❏
CA debonder (GPMR6039)
❏
CA applicator tips (GPMR6033)
❏
CA accelerator (GPMR6034)
❏
Milled Fiberglass (GPMR6165)
❏
Epoxy Brushes (GPMR8060)
❏
Mixing Sticks (GPMR8055)
❏
Builder’s Triangle Set (for fin alignment, HCAR0480)
❏
Felt-Tip marker (TOPQ2510)
❏
Small metal file
❏
Rotary tool such as Dremel ® Moto-Tool ®
❏
Rotary tool reinforced cut-off wheel (GPMR8020)
❏
Sealing iron (TOPR2100)
Optional Supplies & Tools
Adhesives & Building Supplies
Hardware & Accessories
ADDITIONAL ITEMS REQUIRED
4
