The recommended engine/motor size for the Reactor .46 3D
ARF is a .46-.51 two-stroke, .70 four-stroke, or a RimFire
C42-60-480kV brushless out-runner motor. Engine and
motor order numbers are provided below:
❏
O.S. ® .46 AX 2-Stroke ABL w/Muffler (OSMG0547)
❏
O.S. FS-70 II Surpass ™ 4-Stroke (OSMG0872)
❏
O.S. Exhaust Manifold Inside FS-70/FS-91 (OSMG2624)
This manifold is optional and will route the muffler along
the bottom of the fuselage to avoid having to cut a
muffler hole in the cowl.
❏
Great Planes RimFire 42-60-480 Brushless Motor
(GPMG4715)
❏
Great Planes Brushless Motor Mount Medium Motors
(GPMG1255)
❏
Great Planes Silver Series 60 (SS-60) ESC (GPMM1850)
For a brushless motor installation, two 3200mAh 11.1V
Lithium Polymer battery packs connected in series are
recommended. Order numbers for the battery packs and a
series connector adapter are provided below:
❏
(2) Great Planes LiPo 3200mAh 11.1V 20C Discharge
w/Balance (GPMP0623)
❏
Series adapter Deans Ultra Plugs (GPMM3143)
A cell balancer is required for the battery pack listed above:
❏
Great Planes ElectriFly Equinox LiPo Cell Balancer 1-5
(GPMM3160)
A suitable LiPo charger is also required:
❏
Great Planes PolyCharge4 DC Only 4 Output LiPo
Charger (GPMM3015), or
❏
Great Planes ElectriFly Triton DC Comp Peak Charger
(GPMM3150)
This is the list of hardware and accessories required to finish
the Reactor .46 3D ARF. Order numbers are provided in
parentheses:
❏
R/C foam rubber (1/4" [6mm] – HCAQ1000, or 1/2"
[13mm] – HCAQ1050)
❏
3' [900mm] standard silicone fuel tubing (GPMQ4131)
This is the list of Adhesives and Building Supplies that are
required to finish the Reactor .46 3D ARF:
❏
1/2 oz. [15g] Thin Pro CA (GPMR6001)
❏
1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❏
Pro 30-minute epoxy (GPMR6047)
❏
Masking tape (TOPR8018)
❏
Threadlocker thread locking cement (GPMR6060)
❏
Denatured alcohol (for epoxy clean up)
❏
Drill bits: 1/16" [1.6mm], 5/64" [2mm], 3/32" [2.4mm],
3/16" [4.8mm]
❏
6-32 tap and drill set (GPMR8102) (Glow Engine)
❏
Tap handle (GPMR8120) (Glow Engine)
❏
Small metal file
❏
#1 Hobby knife (HCAR0105)
❏
#11 blades (5-pack, HCAR0211)
❏
Medium T-pins (100, HCAR5150)
❏
Top Flite ® MonoKote ® sealing iron (TOPR2100)
❏
Top Flite Hot Sock ™ iron cover (TOPR2175)
Here is a list of optional tools that will help you build the
Reactor .46 3D ARF:
❏
2 oz. [57g] spray CA activator (GPMR6035)
❏
4 oz. [113g] aerosol CA activator (GPMR6034)
❏
CA applicator tips (HCAR3780)
❏
CA debonder (GPMR6039)
❏
Epoxy brushes 6, (GPMR8060)
❏
Mixing sticks (GPMR8055)
❏
Mixing cups (GPMR8056)
❏
Pliers with wire cutter (HCAR0630)
❏
Hobbico Duster ™ can of compressed air (HCAR5500)
❏
Ernst Charge Receptacle Futaba J (ERNM3001)
❏
Panel Line Pen (TOPQ2510)
❏
Rotary tool such as Dremel ®
❏
Rotary tool reinforced cut-off wheel (GPMR8200)
❏
Servo horn drill (HCAR0698)
❏
Hobby Heat ™ micro torch (HCAR0755)
❏
Dead Center ™ Engine Mount Hole Locator (GPMR8130)
❏
AccuThrow ™ Deflection Gauge (GPMR2405)
❏
CG Machine ™ (GPMR2400)
❏
Precision Magnetic Prop Balancer (TOPQ5700)
❏
Hobbico Flexible 18" Ruler Stainless Steel (HCAR0460)
❏
Top Flite MonoKote trim seal iron (TOPR2200)
❏
Top Flite MonoKote heat gun (TOPR2000)
❏
Hobbico Pin Vise 1/16 Collet w/6 Bits (HCAR0696)
❏
Hobbico 8-Piece Ball Tip Hex L Wrench SAE (HCAR0520)
❏
Great Planes Precision Prop Reamer Standard
(GPMQ5006)
❏
Great Planes Precision Prop Reamer Metric (GPMQ5007)
Optional Supplies and Tools
Adhesives and Building Supplies
Hardware and Accessories
ADDITIONAL ITEMS REQUIRED
Batteries and Charger
Power System Recommendations
