ALSO AVAILABLE FROM GREAT PLANES
Improve your fuel economy and increase your power with the
FS-70 Surpass II. It puts out an impressive 1.1 horsepower
at 11,000 rpm – with all the power you need to execute big
maneuvers. Its Type 60R carb provides more precise fuel
flow control and smoother throttle control than the original
FS-70 Surpass. The FS-70 Surpass II also features easier
installation, adjustment and maintenance. Muffler and glow
plug included. Two-year warranty. (OSMG0872) Ask the pilot who owns one, and the reasons to buy mount
up fast. Start with 1.65 hp output from a 17.2 oz. engine.
Add ABL (Advanced Bimetallic Liner) durability, a self-
leveling and aligning head design, a tapered low-speed
needle to eliminate transition “surge” and the.46 AX still has
more to offer. There’s a simple rotor guide screw for low-end
adjustment - and the high-speed needle includes both a
ratchet spring and O-ring seal to lock settings in for the long
haul. Includes A3 glow plug, E-3010 muffler, and 2-year
warranty protection. (OSMG0547)
Displacement: 0.70 cu in (11.50cc)
Bore: 1.02 in (25.8mm)
Stroke: 0.866 in (22.0mm)
Output: 1.1hp @ 11,000 rpm
Practical rpm range: 2,000 to 12,000 rpm
Weight w/muffler: 20.65 oz (585.4g)
O.S. ® FS-70 Surpass ™ II O.S. ® .46 AX ABL
Displacement: 0.455 cu in (7.5cc)
Bore: 0.866 in (22.0mm)
Stroke: 0.772 in (19.6mm)
Output: 1.65 bhp @16,000 rpm
RPM Range: 2,000-17,000
Weight w/muffler: 17.2 oz (489g) Includes: #A3 glow plug, E-3010 muffler
Requires: glow fuel, prop
Suggested prop sizes: 10.5x6, 11x6-8, 12x6-7
For convenience with multiple LiPo packs, there's the DC
PolyCharge4. Each of its four independent outputs can
charge a one-to-four cell Lithium-Polymer pack. It's ideal if
you don't have the time for one-at-a-time charging - and
don't want the expense and hassle of multiple chargers.
Each output can handle packs from 300 to 3000mAh. Set
the capacity, and PolyCharge4 will automatically set the
charge rate to get you started - and use light and sound
cues to tell you when your pack is done. (GPMM3015)
ElectriFly ™ PolyCharge4 ™
Ideal for scale aircraft, bigger sport aerobats, 3D planes, and
larger electric models, the Power Series 3200mAh LiPo pack
enables you to enjoy the benefits of balancing. The cells are
conditioned to last longer, and can be fully charged to 4.20V,
ensuring maximum power from the pack. A LiPo Cell Balancer
(like ElectriFly's Equinox LiPo Balancer GPMM3160) or a
Balancing Charger is required. (GPMP0623)
ElectriFly ™ 3200mAh Power Series LiPo
Battery with Balance Connector
# of Cells in Series: 3 Rated Voltage: 11.1V
Max. Charge Voltage: 12.6V Min. Discharge Voltage: 7.5V
Maximum Recommended Charge Current: 3.2 amps
Continuous Discharge Current: 64 amps (20C)
Discharge Lead: 12 AWG 80mm long wire w/Deans Ultra Female plug
Charge Lead: 24 AWG 40mm long wire w/balance connector
Pack Dimensions: 144x48x24mm (5.66x1.88x0.94 inches)
Weight: 270g (9.52oz)
