24
o 1 . Please read and understand the Proper Pushrod
Hookup illustrations and guidelines on page 25 .
o 2 . Measure and set the control throws according to the
chart below .
NOTE: The throws are measured at the widest part of the
elevators, rudder and ailerons .
These are the recommended
control surface throws:
ELEV
A
TOR
R
UDDER
AILER
ONS
HIGH RATE
1-1/8"
[29mm]
10°
Up
1-1/8"
[29mm]
10°
Down
1-3/4"
[44mm]
22°
Up
1-3/4"
[44mm]
22°
Down
3"
[76mm]
15°
Right
3"
[76mm]
15°
Left
LOW RATE
7/8"
[22mm]
7°
Up
7/8"
[22mm]
7°
Down
1-3/8"
[35mm]
17°
Up
1-3/8"
[35mm]
17°
Down
2"
[51mm]
10°
Right
2"
[51mm]
10°
Left
3D RATE
4-1/4"
[108mm]
38°
Up
4-1/4"
[108mm]
38°
Down
2"
[51mm]
26°
Up
2"
[51mm]
26°
Down
8"
[203mm]
44°
Right
8"
[203mm]
44°
Left
