2 6" [150mm] servo extensions (HCAM2701 for
Futaba) (outer aileron servos)
❏
3 Y-harnesses (HCAM2751 for Futaba) (inner aileron
servos and rudder servos)
❏
2 12" [300mm] servo extensions (HCAM2711 for
Futaba) (receiver to each wing)
❏
1 24" [610mm] servo extension (HCAM2721 for
Futaba) (rudder servos)
❏
1 36" [914mm] servo extension (HCAM2726 for
Futaba) (elevator servos)
❏
Receiver battery, 2000mAh minimum
RUDDER SERVO OPTIONS:
The large size of the rudder on the Giant CAP 580 requires
a lot of servo torque. Our testing shows that less than 300
inch ounces of servo power results in rudder “blow back”
during certain maneuvers. We have three recommendations
to provide adequate performance:
A. The instructions are written for two quarter scale Futaba
S5050 servos. This is the recommended setup.
B. It is possible to use standard size high torque servos
ganged together. There are two servo openings on either
side of the fuse for standard size servos. A 150+ oz/in
standard size servo can be installed on either side of the
fuse. Two 2" [50mm] servo arms will need to be purchased.
C. Four standard size high torque servos (with a total of 300+
oz/in torque) can be used. This is the least recommended
of the setups, and will require modifications not covered in
this manual to install the 4 servos.
The recommended engine size range for the Great Planes 1/3-
scale Matt Chapman CAP 580 is 4.2-7.2 cu in [80-120cc]. The
DA100 provided fantastic power with unlimited vertical and the
weight balanced nicely. If an engine in the upper end of the
size range is used, remember that this is a scale model that is
intended to fly at scale-like speeds, so throttle management
must be practiced.
In addition to the items listed in the “Decisions You Must
Make” section, following is the list of hardware and accessories
required to finish the Great Planes 1/3-scale Matt Chapman
CAP 580. Order numbers are provided in parentheses.
❏
Suitable propeller
❏
R/C foam rubber 1/2" [13mm] - HCAQ1050
❏
3' [900mm] gasoline fuel tubing (GPMQ4135)
❏
Engine kill switch (GPMG2150) (if using a gas engine)
In addition to common household tools and hobby tools, this
is the “short list” of the most important items required to build
the Great Planes 1/3-scale Matt Chapman CAP 580.
Great
Planes Pro ™ CA and Epoxy glue are recommended.
❏
1 oz. [30g] Thin Pro CA (GPMR6002)
❏
1 oz. [30g] Medium Pro CA+ (GPMR6008)
❏
Pro 30-minute epoxy (GPMR6047)
❏
Pro 6-minute epoxy (GPMR6045)
❏
Microballoons (TOPR1090)
❏
Drill bits: 1/16" [1.6mm], 5/64" [2mm], 3/32" [2.4mm], 7/64"
[2.8mm], 1/8" [3.2mm], 9/64" [3.6mm], 5/32" [4mm], 11/64"
[4.4mm], 3/16" [4.8mm], 13/64" [5.2mm], 7/32" [5.6mm],
15/64 [6mm], 1/4" [6.4mm], 17/64" [6.7mm], 9/32" [7.1mm]
❏
Tap handle (GPMR8120)
❏
Small metal file
❏
Velcro ® hook & loop (1" x 6" [25 x 150mm], GPMQ4480)
❏
Stick-on segmented lead weights (GPMQ4485)
❏
#1 Hobby knife (HCAR0105)
❏
#11 blades (5-pack, HCAR0211)
❏
Single-edge razor blades (10-pack, HCAR0212)
❏
Medium T-pins (100, HCAR5150)
Here is a list of optional tools mentioned in the manual that
will help you build the Great Planes 1/3-scale Matt Chapman
CAP 580.
❏
4 oz. [113g] aerosol CA activator (GPMR634)
❏
CA applicator tips (HCAR3780)
❏
CA debonder (GPMR6039)
❏
Epoxy brushes (6, GPMR8060)
❏
Mixing sticks (50, GPMR8055)
❏
Mixing cups (GPMR8056)
❏
Pliers with wire cutter (HCAR0630)
❏
Robart Super Stand II (ROBP1402)
❏
Masking tape (TOPR8018)
❏
Milled fiberglass (GPMR6165)
❏
Threadlocker thread locking cement (GPMR6060)
❏
Denatured alcohol (for epoxy clean up)
❏
Rotary tool such as Dremel ®
❏
Rotary tool reinforced cut-off wheel (GPMR8200)
❏
Servo horn drill (HCAR0698)
❏
Laser incidence meter (GPMR4020)
❏
36" bar for incidence meter (GPMR4021)
❏
Top Flite ® MonoKote ® sealing iron (TOPR2100)
❏
Top Flite MonoKote trim seal iron (TOPR2200)
❏
Top Flite MonoKote heat gun (TOPR2000)
Covering Tools
Optional Supplies and Tools
Adhesives and Building Supplies
Hardware and Accessories
ADDITIONAL ITEMS REQUIRED
Engine Recommendations
