Great Planes PowerMatch - GPMM3220 User Manual
Instruction manual, Power meter with balancing

INSTRUCTION MANUAL
Power Meter with Balancing
GPMM3220 v2
Entire Contents © 2015 Hobbico,
®
Inc. All rights reserved.
™
I N S T R U C T I O N S
The PowerMatch meter is a perfect device for matching electronic
components to optimize electric fl ight performance and satisfaction.
An easy-to-read 216 LCD, easy menus, and high quality input/
output connections make it simple to measure cell voltages, pack
voltages, current, power, remaining battery capacity, and more!
Match propellers to motors for optimum performance. Match battery
packs to motors. Determine system loads. It even includes a built-in
balancer which is perfect for conditioning up to 7S LiPo or LiFe
packs! The PowerMatch meter is an extremely handy and useful
tool for the workbench or fl ight line.
It is strongly recommended to completely read
this manual before use! Damage resulting from
misuse or modifi cation will void your warranty.
