PARTS & ASSEMBLY SHEET

Fixture Name: AUTUMN TWILIGHT 9903-BA3

This fixture assembled PO:

Notice:

Date:

Please review the parts listing and check for all parts before assembling the fixture. If any parts are missing or

damaged, please note on this sheet and contact the place of purchase to arrange for replacement parts.

PARTS LIST

Mounting Strap

Φ102 ㎜ 1ea

Wire Connectors

Orange 3ea

Crystal Leaf

PT-CRYSTAL-9903 LEAF

Company Name:______________________Co Account#:__________

below to be filled out by retailer

Green Screw

G8/32*H8 ㎜ 1ea

Hex Nut

G5/32*H4 ㎜ 2ea

Bulbs

3ea Halogen,

Type G9 40W

Mounting Screws

H32 ㎜ 2ea H38 ㎜ 2ea

Deco Nut

Φ12 ㎜ 2ea

20ea W27*H65 ㎜

Part Needed ______________________________

Comments

Quantity _________________________________

Reason why (missing, scratched, broken glass, bent, bad finish)

__________________________________________________________________________

9903-BA3

Fig.1

FIXTURE ASSEMBLY INSTRUCTIONS

Read and review installation instruction sheet

before assembling the fixture

1.Open the bag that is attached to the fixture and
carefully arrange the bead strings.
2. Screw Crystal Leaf (A) on the arm.
Hold carefully by the metal base to prevent the
crystal from cracking.

3. Place the Glass (C) and Piece (D) over the Socket
(B) and secure with Socket Ring (E).
4. Install the light bulbs in accordance with the
fixture's specification.
Bulb note: Use a tissue or paper towel to hold the
bulb and push down into socket. Oils or dirt can
cause the bulb life to shorten. Rubbing alcohol is
recommended to clean the bulbs if dirty.

(DO NOT EXCEED THE MAXIMUM WATTAGE RATING!)

NOTE: INSTALL THE GLASS ASSEMBLY

AFTER FIXTURE IS HUNG.

For Customer Service, contact the place of purchase to arrange for replacement parts.
