Golden Lighting 8118-M3 PW User Manual
Parts & assembly sheet, Parts list

1ea ∅6"*H1-3/4"
2ea 8#32-IP*1"
1ea 1/4-IP*H60mm
1ea 6ft 3.8mm
3ea P3 Orange
1ea 1/4-IP*H75mm
2ea 5.8*H61mm
1ea 1-1/4"*H42mm
1ea W4-1/8"*E1"*H5mm
1ea 1-1/2"*H5mm
1ea 2-1/4"*H42mm
1ea 1-1/2"*H5mm
1ea 1-1/4"*H49mm
1ea 1/8-IP*H55mm
1ea 4"*H300mm
Part Needed
Quantity
Part Needed
Quantity
Reason why
( missing, scratched, broken glass, bent, bad finish)
Comments
PARTS & ASSEMBLY SHEET
Notice:
Please review the parts listing and check for all parts before assembling the fixture. If any parts are missing or
damaged, please note on this sheet and contact the place of purchase to arrange for replacement parts.
Fixture Name: Alston Place 8118-M3 PW
Center column
Chain connector
Canopy loop
with Collar
Mounting strap
Mounting Screws
Top loop
PARTS LIST
This fixture assembled PO:__________ Date: ________
Chain
Bottom cap (T)
Crystal ball
Bottom cap (W)
to be filled out by retailer
For Customer Service, contact the place of purchase to arrange for replacement parts.
ASSEMBLING THE FIXTURE (Fig.1)
1. Thread the Center Column (L1) to connector (R) till
tight.
2. Feed the fixture wires through the Top loop (J) and
pull the wires until taut.
3. Then screw the Top Loop (J) to the threaded center
column of Frame (M) until tight.
Wire connectors
Fig 1
NOTE: I
NSTALL THE GLASS ASSEMBLY
AFTER THE FIXTURE IS HUNG.
Read and review installation instruction sheet
before assembling the fixture.
8118-M3 PW
F
IXTURE
A
SSEMBLY
I
NSTRUCTIONS
Finial
Nipple
Canopy
Company Name:_______________________Co. Account #:_____________
Nipple
