For Customer Service, contact the place of purchase to arrange for replacement parts.
PARTS & ASSEMBLY SHEET
Fig 2
Fixture Name: Alston Place 8118-6 PW
ASSEMBLING THE FIXTURE (Fig.2)
4. By measuring determine correct number of links
needed for proper hanging height. Use a pair of pliers to
open one link of the Chain (C2) then remove the excess
Chain (C2) and discard it.
5. Use one chain connector (E2) to attach one end of the
chain to the Top loop (D2) and close the chain connector.
6. Feed the fixture wires through the Chain (every three
links) and pull the wires until taut.
7. Slip Canopy loop collar (B2) over the chain, then do the
same with the canopy (F2).
8. When ready to complete the installation Use the other
chain connector and attach the other end of the chain to
the canopy loop (A2) and close the chain connector.
9. Make sure the weight of the chandelier will be
supported by the chain-not the electrical wire.
* You may now install the fixture.
Note: Complete these remaining steps after the fixture is
hung.
10. Thread the Nipple (V) to connector (S),and slide the
Bottom cap (T), Crystal glass ball (U),Bottom cap (W) on
one by one, then use Finial (X) to thread tight.
11. Place the Glass Shades (O) over the Threaded
sockets (P),secure the Glass Shades (O) by threading by
the Socket Rings (N) until tight.
12. Install the light bulbs in accordance with the fixture's
specifications.
(DO NOT EXCEED MAXIMUM WATTAGE RATING)
