For Customer Service, contact the place of purchase to arrange for replacement parts.
10. Thread nipple (70mm)(C) into the coupling and
secure with nut.
11. Place the Bottom Cap (D) over the nipple (C)
and secure with finial (E).
12. Place Glass Shade (F) over the socket and
secure with Socket Ring (G).
13. Install the bulbs as specified. (no bulbs
included in the package).
(DO NOT EXCEED MAXIMUM WATTAGE RATING!)
Fig 5
PARTS & ASSEMBLY SHEET
Fixture Name: Loretto 4002-9 RSB
3. Feed the fixture wires through the Top loop
(D2) and pull the wires until taut. Then screw
the Top Loop（D2） to the coupling on the top of
fixture (A) until tight.
4. By measuring determine correct number of links
needed for proper hanging height. Use a pair of
pliers to open one link of the Chain (C2) then
remove the excess Chain (C2) and discard it.
5. Use one chain connector(E2) to attach one end
of the chain to the Top loop (D2) and close the
chain connector.
6. Feed the fixture wires through the Chain (every
three links) and pull the wires until taut.
7. Slip Canopy loop collar (B2) over the chain, then
do the same with the canopy (F2).
8. When ready to complete the installation Use the
other chain connector and attach the other end of
the chain to the canopy loop (A2) and close the
chain connector.
9. Feed the fixture wires through canopy loop (F)
and nipple(C) and pull until taut.
Fig 4
B2
A2
C2
E2
D2
E2
