INTRODUCTION
The 7909 is Alpine's audiophile compact disc player and FM/
AM digital PLL synthesizer tuner combined in one DIN-sized
chassis. It incorporates the most refined CD laser pickup and
transport in mobile audio, along with Alpine's famous T-10 II
tuner which provides exceptionally stable reception, excellent
signal-to-noise characteristics and ultra-wide frequency re
sponse. It includes the controls which allow direct interface with
Alpine's compact disc changers CHM-S601 or CHA-S604. The
7909 allows for ultimate single play CD reproduction and the
convenience of multi-disc playback for any system configuration
you desire. Please read this manual thoroughly to familiarize
yourself with each control and function. We, at Alpine, hope you
have many years of enjoyment from your 7909.
CONTENTS
INTRODUCTION..................................................................................................................................................6
OPERATION
INSTALLATION................................................................................................................................................ 18 & 19
IMPORTANT NOTICE........................................................................................................................................22
SPECIFICATIONS............................................................................................................................................. 28
INDICATION FOR CD SHUTTLE
INDICATION
CAUSE
SOLUTION
C _
n
1
C U 1
Disc-change malfunction.
Consult your Alpine dealer.
c _
n
p
L U C
Disc is in the changer
mechanism.
Press the magazine eject
button, and insert an empty
magazine.
c
_ n
J
L U J
c _ n u
C
U
1
c _ n c
L U _i
Disc-change malfunction.
If the code disappears within
a few seconds, the unit is
OK.
If not, consult your Alpine
dealer.
P - >~'P
C U Q
Disc-change malfunction.
Press the magazine eject
button and pull out the
magazine. Check for no error
indication. Try again, if the
magazine cannot be pulled
out, consult your Alpine
dealer.
c
_ n n
C U
1
Magazine ejection impossi
ble.
Press the magazine eject
button.
If the magazine does not
eject, consult your Alpine
dealer.
t ~ J U
High temperature.
Will disappear when the
temperature returns to
operation range.
E E E E
Incorrect connection or
disconnection of the CD
changer.
Check connection between
the CD changer and the
control unit.
—
No CD magazine in the
CD changer.
Insert the CD magazine.
_ _ _ D
1
1
u L
No CD at No. 2 slot of the
CD magazine.
Insert a CD into the No. 2
slot of the CD magazine.
