ETTING
Setting the Video Channel
This VCR is designed to send picture and sound signal on UHF channel E36 to the TV, through tlie RF coaxial cable.
If you want to change this video channel (E36) to another channel (between E28 to E60), follow the procedure below
before turning on the VCR for the first time.
1
Keep the VCR turned off and no cassette inserted until you finish the following procedure.
2
Turn on the TV, and tune it to any channel (UHF E28 to E60) you want to use as the video channel on the TV.
• Select a channel not used in your area.
3
Press STOP/EJECT ■ on the front panel for more than 5 seconds.
The following indication appears on the display.
mu T -,r
uju I zlb
TV system number starts flashing.
4
Press CH A / T on to select an appropriate TV system number for your area.
l:ForB/G.
2:ForD/K.
3:ForI
5
Press OK/^.
The channel number starts flashing on the display.
jni I T -,r
L LIU i zlb
Channel number starts flashing.
6 Press CH A / ▼ to select the channel you have tuned on the TV as the video channel in step 2.
A test signal (two vertical v.'hite bars) appears on the TV.
Test signal
(two vertical white bars)
If you use only external video input ('.f t'l mode to
watch the picture from this VCR
You can turn off the video chamit I ou’piit. To turn ojf
the video output channel, press CH until "—” appears
on the channel number position.
7 Press OK/^ to finish the video channel setting.
Now you will enter the Initial Setup mode explained on page 11.
To watch a picture from this VCR on the TV, select the same channel you have selected as the video channel (in step 2
above) on the TV.
— 10-
