18
Troubleshooting
RANGE IS SHORT
Interference – check Rx installation and servo connections.
Low Tx or Rx battery – replace the batteries or recharge
if applicable. Rx may need to be located to a different
position in the model for better reception. Crash damage –
send the radio to Hobby Services for repair.
RUN TIME IS SHORT
Low Tx or Rx batteries – replace or recharge the batteries.
Obstructed servo linkages causing excess battery drain –
free the linkages / pushrods.
Tx POWER SWITCH ON BUT SERVOS DO NOT FUNCTION
Tx or Rx batteries are low – replace or recharge the
batteries. Rx switch is in the off position – turn on the
ESC or switch harness. Switch harness or ESC is
connected incorrectly – check all connections and the
ESC instruction manual. Rx is not binded to the Tx
properly – perform binding process again. Check Tx or
Rx battery polarity.
INTERFERENCE OR SERVOS GLITCHING
Out of range – operate the model more closely to the
transmitter. Outside radio interference from pagers, strong
industrial or other commercial transmitters in the area
- check your local R/C club regarding local operation. Rx
located too closely to engine, motor, or servos or other
moving mechanical parts which might be creating unwanted
electrical noise – relocate the Rx inside the model or
relocate the ESC.
CONTROL SURFACE MOVES IN THE WRONG DIRECTION
Reverse the position of the reversing switch for the
appropriate channel.
ONLY ONE SERVO GLITCHES
Servo is bad – replace the servo or send to Hobby Services
for repair.
FAILSAFE NOT WORKING CORRECTLY
Receiver is not properly binded to the transmitter – bind
the Rx to the Tx and re-try. Contact Hobby Services for
further details.
WIRELESS TRAINING FUNCTION NOT BINDING
Check to see that another Tactic 2.4GHz system is not on
in your area. The teacher’s and student’s transmitters were
not powered in the proper sequence. Carefully follow the
instructions on page 15 for proper binding and operation
for training.
RECHARGEABLE BATTERIES WON’T ACCEPT CHARGE
THROUGH THE TRANSMITTER
Check the charger for proper setup and operation. Make
sure the charge plug is inserted fully into the charge
jack. Make sure the transmitter’s power switch is in the
OFF position. Make sure the cells are inserted inside the
battery compartment in the proper direction.
FCC Statement
This device complies with part 15 of the FCC rules. Operation
is subject to the following two conditions.
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
FCC Rf Radiated Exposure Statement: The
equipment complies with FCC Rf radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of
20 centimeters between the radiator and your body.
Note: The manufacturer is not responsible for any radio
or TV interference caused by unauthorized modifi cations
to this equipment. Any changes or modifi cations
not expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
FCC ID: IYFTTX600
CE Compliance Information
for the European Union
Instructions for Disposal of Waste Equipment
by Private Users in the European Union:
This symbol on the product or its packaging
indicates this product must not be disposed of
with other household waste. Instead, it is the user’s
responsibility to dispose of their waste equipment by
handing it over to a designated collection point for the recycling
of waste electrical and electronic equipment. The separate
collection and recycling of your waste equipment at the time
of disposal will help to conserve natural resources and ensure
that it is recycled in a manner that protects human health and
the environment. For more information about where you can
drop off your waste equipment for recycling, please contact
your local city offi ce, your household waste disposal service
or location where you purchased the product.
Declaration of Conformity:
Product: Tactic TTX600 2.4GHz
6-Channel Tx Rx
Item number: TACJ2600
Equipment class: 1
Tactic TTX600 transmitter and Tactic TR624 receiver:
The objects of the declaration described here are in conformity
with the requirements of the specifi cations listed below,
following the provisions of the European 2006/95/EC Low
Voltage Directive:
EN 60950-1:2006 Safety
