17
7. I will not operate models with pyrotechnics (any device
that explodes, burns, or propels a projectile of any kind).
RADIO CONTROL
1. I will have completed a successful radio equipment ground
check before the first flight of a new or repaired model.
2. I will not fly my model aircraft in the presence of spectators
until I become a qualified flier, unless assisted by an
experienced helper.
3. At all flying sites a straight or curved line(s) must be
established in front of which all flying takes place with the
other side for spectators. Only personnel involved with
flying the aircraft are allowed at or in the front of the flight
line. Intentional flying behind the flight line is prohibited.
4. I will operate my model using only radio control frequencies
currently allowed by the Federal Communications
Commission.
5. I will not knowingly operate my model within three
miles of any pre-existing flying site except in
accordance with the frequency sharing agreement
listed [in the complete AMA Safety Code].
9. Under no circumstances may a pilot or other person touch
a powered model in flight; nor should any part of the
model other than the landing gear, intentionally touch
the ground, except while landing.
Specifi cations
TTX600 6-Channel Transmitter
Channels 6
Frequencies 2.403 – 2.480GHz
Modulation FHSS spread spectrum
Input power Four “AA” alkaline, NiCd,
or NiMH cells (3.8 – 8.0V, not included)
Output power < 0.1W
Power indicators LED, with low voltage alarm
Reversing switches Slide switches, four channels
Trims Analog for throttle,
digital for aileron, elevator, rudder
Antenna Built-in non-removable
Optional mixes Elevon, V-Tail
Dual rates 100/60 % for aileron/elevator/rudder
Channel 5 Non-proportional on/off
Channel 6 Proportional
Trainer function Wireless
(compatible with Tactic brand transmitters only)
Charge jack Built-in (Futaba ® compatible,
for use with optional NiCd or NiMH cells)
Tactic TR624 Receiver
Channels 6
Frequencies 2.403 – 2.480GHz
Modulation FHSS spread spectrum
Input power Four “AA” alkaline,
NiCd or NiMH cells (4.0 – 6.0V, not included)
Failsafe Programmable throttle, all other channels hold
Dimensions 1.77 Ч 0.98 Ч 0.5" (45 Ч 25 Ч 13mm)
Weight 0.28 oz (8g)
Important Warnings and Precautions
● NEVER allow water or moisture to make
contact with the electronic components
inside the transmitter, receiver, servos, switch
harness, etc.! This could lead to failure or
improper functionality of components and poor control of
aircraft which could pose a safety hazard.
● NEVER operate R/C model aircraft near power lines, radio
or cell phone towers, roads or automobiles, buildings, or
pedestrians. Be very careful in locations where many R/C
aircraft are being used simultaneously.
● NEVER operate R/C equipment if you are physically
impaired as it could pose a safety hazard to yourself or
others in the area.
● NEVER allow small children to operate/control model R/C
equipment without the supervision of an adult.
● NEVER allow the transmitter’s throttle stick to accidentally
be moved away from the “off” or minimum position while
the model’s engine/motor is moving.
● ALWAYS range check the radio system before use.
● ALWAYS make sure that all transmitter stick movements
operate all servos properly in the model. Check the proper
operation of control surfaces before and after starting the
engine/motor.
● ALWAYS make sure the transmitter antenna is unfolded
entirely so that it’s pointing upright to ensure max. range
and control of the aircraft.
● Do not store your radio equipment in extremely hot or
cold locations, in direct sunlight, or in locations with high
humidity. Store R/C equipment in cool and dry locations.
● Do not allow chemicals to come in contact with any
parts of the radio system. Substances such as glow fuel,
gasoline, CA glue, etc. could permanently damage plastic
parts of the radio system.
● If NiCd batteries were installed in the transmitter, remove
the batteries before placing the radio in long-term storage.
