6
FIGURE 1: SIZE 10, 12, 15, & 18 FIGURE 2: NO SPREADER BARS
FIGURE 3: WITH SPREADER BARS FIGURE 4: ACCESSORIES
CAUTION!!
These are unbalanced loads
Lift equipment gently
Do not jerk
WARNING!!
Spreader bars must be used and should extend
past the edges of the equipment to avoid damage
to the casing. Not using spreader bars may cause
damage to the casing
WARNING!!
Damage will result if the equipment is raised by the intake hood, blower, motor shaft, or bearings
Use the provided lifting eyes and brackets on the unit
Curbs
The unit must have adequate structural support or the equipment or building could be damaged. The curb
and unit must be leveled or the unit may leak or be damaged. Use gasket and caulk between the curb
and unit. Use shims if necessary to level the unit. Screw or weld the unit’s base to the curb to avoid
damage to the equipment.
