Setup, 6 setup [0--] interface block, ] serial interface 1 (standard serial interface) – Flintec FT-13 User Manual
Page 36: ] serial interface 2 (optional serial interface), 000 x ] data format, 001 x] baud rate, 002 x] handshake, 003 xx] address, 004 x] data length and parity, 005 x] checksum

FT-13 Technical Manual, Rev. 1.40 March 2013
Page 36 of 56
Start
: Start time of the first filling / discharging cycle
End
: End time of the last filling / discharging cycle
N
: Number of filling / discharging cycles
NC
: Number of controlled filling / discharging cycles
Control Conditions:
Preact correction is done (see parameter [502] in chapter 7.6)
The filling / discharging weight must be within the preact
correction limit. (see parameter [503] in chapter 7.6)
N : Number of filling / discharging cycles below tolerance N>t : Number of filling / discharging cycles above tolerance Nok : Number of filling / discharging cycles within tolerance Avg : Average value of the filling / discharging weight value S : Standard deviation. Only controlled filling / discharging cycles are evaluated Min : Minimum filling / discharging weight value Max : Maximum filling / discharging weight value R : Maximum weight value – Minimum weight value Total : Total weight of filling / discharging If the filling / discharging weight is controlled, the exact filling or 8.2.6 Setup [0--] Interface Block You can access the parameters of the instruments‟s serial interface(s) in parameter section [0--]. The data output modes [00-] Serial Interface 1 (Standard serial interface) [000 X ] Data Format 0 : No data transfer 1 : Continuous data output 2 : Print mode 3 : Host mode [001 X] Baud Rate 0 : 1 200 Baud 1 : 2 400 Baud 2 : 4 800 Baud 3 : 9 600 Baud 4 : 19 200 Baud 5 : 38 400 Baud 6 : 57 600 Baud [002 X] Handshake 0 : No Handshake 1 : Xon/Xoff [003 XX] Address You can define a device address between 1 and 99 by this parameter. Entry 0 no address. [004 X] Data Length and Parity 0 : 8 bit, no parity 1 : 7 bit, odd parity 2 : 7 bit, even parity [005 X] Checksum 0 : Checksum byte disabled 1 : Checksum byte enabled [02-] Serial Interface 2 (Optional serial interface) [020 X ] Data Format 0 : No output 1 : Continuous data output 2 : Print mode 3 : Host mode 4 : Modbus RTU High-Low* 5 : Modbus RTU Low-High** * Modbus RTU, high word before low word at address 40001 and 40002 [021 X] Baud Rate 0 : 1 200 Baud 1 : 2 400 Baud 2 : 4 800 Baud 0 : 1 200 Baud 4 : 19 200 Baud 5 : 38 400 Baud 6 : 57 600 Baud [022 X] Handshake 0 : No Handshake 1 : Xon/Xoff BATCH REPORT = xxxxxx NC = xxxxxx N = xxxxxx N>t = xxxxxx = xxxxxx kg S = xxxxxx kg Min = xxxxxx kg Max = xxxxxx kg = xxxxxx kg Total = xxxxxx kg
discharging weight is added to the “Total” value. If the filling /
discharging weight is not controlled, the target value is added to the
“Total” value.
(see chapter 8.3) can be used only once except for continuous data output.
** Modbus RTU, low word before high word at address 40001 and 40002
Start : dd.mm.yyyy hh:mm
End : dd.mm.yyyy hh:mm
N
Nok = xxxxxx
Avg
R
