Diagram1 • Normally Close (NC)
Diagram 2 • Normally Open (NO)
Diagram 3 • Other Accessories
EM Lock (NO) +
---
Emergency Break 1
Glass (Type NO) 3
Overwrite Switch B
(Type NO) D
Release Button
DC12V 3A
Power Supply
ALM+
ALM-
NC
COM
NO
BUT
GND
SEN
BEL+
BEL-
GND
+12V
ALM+
ALM-
NC
COM
NO
BUT
GND
SEN
BEL+
BEL-
GND
+12V
Alarm device Type
NO or NC Dry contact
Door Sensor
Doorbell
DC12V 3A
Power Supply
EM Lock (NC)
+
---
Emergency Break 2
Glass (Type NC) 3
Overwrite Switch A
(Type NC) C
Release Button
DC12V 3A
Power Supply
ALM+
ALM-
NC
COM
NO
BUT
GND
SEN
BEL+
BEL-
GND
+12V
Front View of R2 Front View of R2c
13mm
15mm
3mm
Appendix II
Terminal Dimensions and Measurements
Appendix I
Power Supply & Door Lock System Wiring Diagrams
Door Lock Connectors
The terminal will trigger the alarm
output (NO or NC) for the follow-
ing situations:
• Door forced open (A door sensor
must first be installed)
• Door open time out (A door sen-
sor must first be installed)
• Terminal has been illegally dis-
mantled
Dry Contact (independ-
ent power supply for door
lock)
• NO type door lock (NO-
COM)
• NC type door lock (NC-
COM)
Power Contact (using
power from terminal to
power on door lock)
• NO type door lock (NO-
GND)
• NC type door lock (NC-
GND)
Dry Contact (independ-
ent power supply for door
lock)
• NO type door lock (NO-
COM)
• NC type door lock (NC-
COM)
Power Contact (using
power from terminal to
power on door lock)
• COM1 - +12V
Door Sensor
(SEN-GND)
Release button
(BUT-GND)
Door Bell
Alarm System
NO or NC Type – Check in
Advance Options
WIRING PORT USAGE
NO
NC
COM
SEN
GND
BUT
Bell+
Bell-
AL+
AL-
