Replacement Parts
Stock
No.
Key
No. Description
DLEG3001 1 Cylinder Head
DLEG3002 2 Crankshaft w/Con Rod
DLEG3003 3 Front Crank Case
30 Rear Crankcase
DLEG3004 4 Piston
27 Piston Pin
28 (2) Piston Pin Retainers
DLEG3005 5 Piston Ring
DLEG3006 6 Electronic Ignition Module
DLEG3007 7 Muffl er with Gasket (2) 5x20mm SHCS
DLEG3008 8 Carburetor Complete
DLEG3009 9 Engine Mounting Standoffs
with (4) 5mm Flat Washers & (4) 5mmx60mm SCHS
DLEG5510 10 Spark Plug
DLEG3012 12 Rear Bearing
25 Front Bearing
DLEG3013 13 Electronic Ignition Sensor with Mounting Screws
DLEG3015 15 Complete Screw and Washer Set
DLEG3016 16 Propeller Hub
22 Crankshaft Spacer
23 Crankshaft Extension
24 Propeller Washer.
DLEG3017 26 Needle Bearing
DLEG3018 17 Carburetor Spacer Gasket
18 Carburetor Gasket
19 Muffl er Gasket
20 Head Gasket.
DLEG3019 29 Woodruff Key
Optional Parts
DLEG5525 Onboard Digital Tachometer
DLEG3035 Rear Carburetor Conversion Kit
30 Rear Crankcase
14 Carburetor Mounting Base
11 Reed Valve Assembly
21 Carburetor Mount
17 Carburetor Spacer Gasket
18 Carburetor Gasket
